Born out of ANSA’s own challenge of enhancing our team’s capabilities through bespoke digital solutions, Clarity™ delivers a unique blend of embedded subject mater expertise, novel methods, performance and accuracy never seen before. It is the most advanced well integrity data platform bar none.

“We build what we wished we had.”
alan_linked
Alan Walsh
CEO ANSA Data Analytics

Unlocking the Power of AI for Well Integrity Analysis and Reporting

Augment - Unlock the true value of your data sets

Clarity™ has redefined what a well integrity data processing software can do, moving away from being a simple toolbox of editors, fully dependent of the experience and proficiency of the end-user.



By deploying the power of our in-house AI framework – PRISM™ – Clarity™ can empower the analyst with automations which cover every aspect of Multifinger Caliper data processing, unlocking accuracy and efficiency gains never-seen before.



From precisely selected, context aware centralisation methods to fully automated depth-correction, calibration and even report writing, Clarity™ offers a new way to achieve expert results without overreliance on user expertise.

Get Clarity™
"Clarity V2 contains some excellent features that are much better than our current caliper processing software. The automatic collar detection and PRISM Depth correction are much easier to use than manual approaches, and I can see this saving us a significant amount of time during the process and reporting."
Senior Technical Services Specialist, Aberdeen
"My first impression is that the software is remarkably smooth and easy to use. Even while I was still learning the platform and inputting my first logs, the experience was great."
Jacob Dixon
Jacob DixonTechnology and Innovation Engineering Lead, Accu-Line Well Services
"We have experienced a huge reduction in output variance simply based on who processed the data. Using Clarity has really helped us all move to a better and more standardised report."
Data Services Team Lead
"Using PRISM and WorkFlow has suddenly made it possible for us to deliver a much better wellsite report. Our customers are very happy with the new deliverable."
Regional Service Delivery Manager
“The addition of the 3D Viewer and the huge speed improvement in Clarity V2 make a huge difference in how we visualise data. It’s a much more intuitive and efficient environment for interpretation.”
Alimzhan Muratkazy
Alimzhan MuratkazyProduction Logging & Well Intervention Specialist, Slickline Services LLP

Clarity V2's performance is up to 7X better than before!

1X

2X

3X

4X

5X

6X

7X

8X

9X

10X

Data Import & Display
PRISM Centralisation
Depth Correction
PRISM Recalibration
Re-orientation
Data Edit
PRISM Joint Detection

Fully customisable. Detail rich. MFC reports, the Clarity™ way.

A successful logging operation only pays its dividends when informed decisions can be made, lowering risks and moving the program forward.



Effectively communicating findings often depends on laying out unambiguous, precisely worded text, multiple graphics, charts and tables, often in your own branded template and in a way that is both easy to comprehend and sets your data product apart.



Meanwhile, the legacy software packages currently known to the industry either have no real report automation capability or simply output generic charts and tabulated data.

Re-writing the rules with PRISM LLM

With Clarity™ you can use our finely tunned PRISM LLM,  specifically trained for delivering professional technical writing directly to your well integrity report.



With one click Clarity™ can auto-generate a full report, with images, supporting charts and tables and, more importantly, with clear findings written in plain English.

"Having a plain English report, with a proper executive summary and detailed, tubing size by tubing size report, all generated with a few clicks at the wellsite is incredibly useful to us."
Senior Field Engineer

WorkFlow - Let Clarity™ and PRISM™ do the hard work

Effective and accurate Multifinger caliper analysis and reporting rests on meticulously controlled workflows. What processes should come first? What are the best parameters for this particular task?



The answers to these questions often make the difference between dependable and actionable well-site intelligence and bad, very bad advice.

Consistency informed by knowledge

WorfFlow is Clarity™’s way to deliver the power of our in-house AI-assisted processing modules in a coherent and organised way, perfectly structured to take the most advantage of its capabilities and  to provide the most accuracy.



What perhaps come as second-nature to a very experience well integrity analyst, with many years of MFC processing under his or her belt, can now be available to everyone.


The right processing step, the right parameter selection, at the right time, every time.

Download the Whitepaper

No black-box

Clarity™ contains ‘hands-on’ versions of all PRISM functions to allow you to take control of each processing step. It also includes various utilities that are not part of PRISM™, allowing for maximum flexibility while processing of a multifinger caliper data set.

Get Clarity™

Import & Export



Import your data in the widely accepted .LAS and .DLIS formats. Export your processed data for delivery to your customer in LAS format.

Unit Conversion



In an ideal processing workflow the imported log values will be defined by the correct unit of measurement. If not you can convert, any log value with a defined unit can be converted into another unit of measurement.

Resampling



It is recommended to work with multifinger caliper data at the maximum acquired resolution to capture the most value from the survey. However, when working with data at different sample rates, or to alter the volume of data, you can up sample or down sample as required.

Tubular Database



With Clarity’s tubular database you can simply select your pipe or casing size from a comprehensive list in order to get all the dimensions you will need during processing. And if the tubular in question does not already exist the database can be updated, with all the required details saved for being used again in the future.

Centralisation



As opposed to the PRISM method, where Clarity makes the best choices at every depth frame, you can also make your own choices manually. The outlier count, the geometric fitting and method of excluding outlier values can be edited. You can also zone your choices differently throughout the survey to account for changes in well condition.

Depth Correction



To complete manual depth correction the user can enter pairs of depths to shift the data as required to either a reference document or curve.

Recalibration



Rather than allowing PRISM to identify effects such as temperature drift or finger wear the user can take control. The user can define the zones of data which will be used to create shift values and the method of calculating the shift values.

Reorientation



A useful feature which ‘rotates’ the data so that the centre of the multi-arm track contains the data representing the high side of the pipe. Helpful when visualising features which are present towards a certain part of the pipe and tool rotation makes it slightly harder to visualise.

Arm Array Edit



Manual edits of data will always be a useful tool to remove spurious values from a dataset. When the arms of the tool are damaged or clogged, these high or low values will obscure the reporting of remaining useful high and low values.

Clarity offers several methods of replacement, so the user can decide on the most suitable technique to substitute the erroneous or misleading values.

Splice & Merge



Various situations such as when you need to import a reference Gamma Ray or merge together two logging runs will require you to splice and merge files together.

After importing the data into Clarity you can choose which curves at selected intervals you want to be present in your output file.

Compute Statistics



The goal of processing is to have the best data available to allow the creation of new calculated curves which enhance the analysis and interpretation of your data.

Clarity adds numerous values, such as penetration percentage, minimum diameter to the project file, available to export to LAS and to use in the joint by joint report later in the reporting workflow.

Processing History



All user interactions with Clarity processing modules are logged and then available to inspect and export at the end of processing.

This allows the end user to inspect all edits, creates an audit report for future inspection and assists is troubleshooting for future users opening the same project.

FAQs

Get Clarity™

Name
Email
Clarity™ uses our in-house AI engine, PRISM, to automatically scan every depth-frame of your data and decide how best to centralise it.
Clarity™ automatically identifies connections, joints and completion items using PRISM™
PRISM™ allows you to have consistent damage identifation and classification, removing analyst bias and
making reporting more reliable.
